1, the winding tube inner diameter: Φ76-Φ250mm

2, winding paper tube thickness: 1-15 mm

3, cut tube length: 1-4 m (any)

Methods: 4, cutting single round blade

5, production speed: 1 to 18 m

6, host power: 11 kw

7, working pressure: 0.6 mpa

8, fixed-length patterns: infrared fixed length

9, gluing system: make PL type plastic frame

10, paper feeding system: make ZT put a paper plane

11, the operation staff: 2-3

12，host, size: 5000 X 1800 X 2100 mm

13， mechanical weight (gross weight) : 3700 kg
